Rapid shape-forming
Viscoelastic Tape System
Viscoelastic Corrosion Protection Paste
A cold-applied, non-curing paste for forming smooth profiles and filling pinholes, voids and depressions before the matching wrap is installed.
Overview
System role and composition
Shape-forming and void-filling component
- Permanently flexible viscoelastic compound
- Shape-forming companion to viscoelastic tape systems
Key advantages
Approved product and system characteristics
Statements below apply only to this product or stated system and must be read with the listed conditions and qualifiers.
Permanently flexible and non-curing
No VOC, no odor and solvent-free
Cold-applied with no hot work
No primer required where used as specified
Cathodic protection compatible and resistant to cathodic disbondment
Fills voids, pinholes and depressions
Typical applications
Where this solution is considered
- Irregular flanges, valves and pumps
- Damaged 3PE systems
- Recesses, transitions and surface depressions
- Classified hazardous environments where a cold-applied, no-hot-work method is technically appropriate
Typical Sizes and Packaging
System formats are selected from the matching component pages.
Packaging
- 4 kg/tin
- 2 kg/block
Product formats, packaging and available grades may vary by application and order requirements. Please confirm the current configuration with our team.
Installation overview
Confirm the complete procedure before work begins
- Confirm compatibility with the selected primary corrosion protection system.
- Prepare the substrate or component surface to the specified system requirement.
- Apply or shape the material continuously over pits, voids and irregular transitions.
- Install the matching primary wrap before contamination or damage can occur.
- Inspect the completed profile and system continuity before adding outer protection.
Matching components
This overview supports early evaluation. The current TDS and approved project procedure remain the controlling installation documents.
Gallery
Product and application views
Related applications
Continue from product to asset
Verified related project evidence
Technical documents
Request the documents relevant to your evaluation
Product catalog, technical data, safety information and installation guidance are supplied according to the selected product and application.
Content source: Zhuohuang Technical Data Sheets UAE 2026 (primary); Zhuohuang Product Catalogue UAE 2026 (secondary).
Frequently asked questions
Does the paste cure?
No. It remains permanently flexible and is designed to maintain the formed profile.
Is it ATEX certified?
No ATEX certification claim is made. The approved statement is suitability for application in classified hazardous environments without hot work where technically appropriate.
Technical inquiry
Confirm the right configuration for your asset
Share the asset type, geometry, existing coating, operating environment and documentation requirements.
Discuss This Product
